BASIC LAYOUT DRAWINGS

This section provides assistance with general shaft requirements for the most frequently requested lift car sizes and arrangements. These drawings are downloadable and should provide Builders, Architects and Developers with good indications of building design requirements for various-size Lift Installations. Downloads are in Portable Document Format (PDF). A PDF-compatible viewer is required to read them.

630kg 1100×1400 Single

Cabin Width: 1100mm Cabin Depth 1400mm
Single Entry 630kg (8 Person)

630kg 1100×2100 Through Car

Cabin Width: 1100mm Cabin Depth 2100mm
Dual Entry 630KG (8 Person)

800kg 1350×1400 Single

Cabin Width: 1350mm Cabin Depth: 1400mm
Single Entry 800kg (10 Person)

1000kg 1100×2100 Through Car

Cabin Width: 1100mm Cabin Depth: 2100mm
Dual Entry 1000kg (13 Person)

1000kg 1100×2100 Single

Cabin Width: 1100mm Cabin Depth: 2100mm
Single Entry 1000kg (13 Person)

1000kg 1400×1600 Single

Cabin Width: 1400mm Cabin Depth: 1600mm
Single Entry 1000kg (13 Person)

1000kg 1400×1600 Through Car

Cabin Width: 1400mm Cabin Depth: 1600mm
Dual Entry 1000kg (13 Person)

1275kg 1200×2300 Single

Cabin Width: 1200mm Cabin Depth: 2300mm
Single Entry 1275kg (17 Person)

1600kg 1400×2400 Single

Cabin Width: 1400mm Cabin Depth: 2400mm
Single Entry 1600kg (21 Person)

1800kg 1600×2400 Single

Cabin Width: 1600mm Cabin Depth: 2400mm
Single Entry 1800kg (26 Person)

2000kg 1500×2700 Single

Cabin Width: 1500mm Cabin Depth: 2700mm
Single Entry 2000kg (26 Person)

2500kg 1800×2700 Single

Cabin Width: 1800mm Cabin Depth: 2700mm
Single Entry 2500kg (33 Person)

2500KG 2100×2300 Single

Cabin Width: 2100mm Cabin Depth: 2300mm
Single Entry 2500kg (33 Person)

Do you need more help after viewing or downloading our drawings, certifications, or accreditations? After visiting our FAQ page you have more questions that haven’t been answered? Then feel free to get in touch with our experienced Design, Sales, and Technical teams by calling on 0115 9737 500 and we will be more than happy to deal with your enquiry.
